Conventional Roll Tarp
Tri-County Tarp's Conventional Roll Tarp System consists of a heavyweight 22oz tarp that is held down perminanently on one side with ratched tie downs on the other. Traditionally there are aluminum end caps on each end. We also offer other cap variations when the traditional aluminum cap cannot be used.
Components of a Conventional Roll System include:
• Bows
• Bow Pockets
• 2 square aluminum end caps
• Roll Pipe
• Perm Pipe (Can be interchanged with Perm Strip)
• Quick Release Caddies which hold the perm strip
• Ratchets with straps
• Crank
• 22oz Conventional Roll Tarp
• Pullback Rope
Optional Features
Bow Cap
On dump trailers when an aluminum cap isn't an option, we instal a bow cap with matching tarp material.
Bow caps are used when a traditional aluminum cap cannot be used. Most often with dump trailers.
A bow cap consists of two bows with a plate welded between them which can serve as the purpose of a traditional aluminum end cap. Bow caps are covered with a matching vinyl material to blend in with your tarp.
Radius Aluminum Cap
Radius Caps, or Ravens Caps can be custom made to fit the trailer if desired.
• Wrap Tail
• Cut Out Tail
• Crap Flap; we can run a piece of vinyl the full length along the side of your tarp to prevent contents of trailer from spilling out.
